Mechanical Assembly

Ready to start?

Helpful Tips

left to right: driver, fastener, washer, lock washer, nut, hex key
Left to right: Phillips driver, fastener, part, washer, lock washer, nut, hex key

1. MPU6050

Materials

MPU6050 attachment
Note: pins point up and fasteners point down
exploded view of MPU6050 attachment
Exploded view: note which side has 3 holes

2. Caster Wheel

Materials

Note:

  • attach base with spacer first
  • no lock washer this time
  • tighten fasteners before attaching ball
  • don't forget the rollers
Caster wheel attachment
exploded view of caster mount attachment
Exploded view of base attachment
exploded view of adding ball
Exploded view of cover attachment

3. Attach Motor Mounts

Materials

Left motor with bracket attached
Left motor with bracket attached
Right motor with bracket attached
Right motor with bracket attached
exploded view of left motor mount attachment
Exploded view of left motor bracket attachment
both motors with their mounts attached
Repeat for right motor, it mirrors the left motor

4. Attach Motors to Frame

Materials

another view of both wheels attached
Once attached, pass wires through holes
exploded view of left motor attachment to frame
Exploded view

5. Optical Interrupt Sensors

Materials

optical interrupt sensors attached
Make sure pins point towards caster wheel
exploded view of optical interrupt attachment
Exploded view

6. Motor Controller Board

Materials

removing jumpers from motor driver
First, remove jumpers from motor controller on ENA and ENB pins
exploded view of adding spacer to motor controller
Attach spacer onto 16mm fasteners
exploded view of motor controller attachment to frame
Attach to frame

7. Raft PCB Attachment

Materials

drawing of the pico raft pcb without the pico attached
v0.3 Raft
exploded view of adding spacers to pico raft
Attach spacer onto 16mm fasteners
exploded view of raft attachment to frame
Attach to frame

8. Fasten Servo Horn to Lidar Sensor Bracket

Materials

exploded view drawing of the lidar sensor bracket with the servo horn attached
Slide the horn into the sensor bracket
exploded view drawing of the lidar sensor bracket with the servo horn attached
Use screwdriver to attach self-tapping fasteners into the outer holes

9. Fasten Servo to Frame

Materials

exploded view drawing of the fasteners used for the servo to frame
Pass servo wires through hole so that they are in the front, route up and down through the 3 holes
exploded view drawing of the lidar sensor bracket with the servo horn attached
Use screwdriver to attach self-tapping fasteners into the frame, be careful to not break the plastic
(its okay if you need hot glue here)

Congrats! You're about halfway

Before moving on to electrical assembly,
check the following:

Once ready to move on: click here

robot so far
